PB Video Pipeline Endoscope

The PB series video pipeline endoscope is a new type of detection device for inspecting the interior of pipelines. It features a wide viewing Angle, large observation range, strong brightness of the lighting source and high resolution.

The hard push cable (GFRP material) is convenient for long-distance feeding of lenses, with a length ranging from 10m to 120m, and can be operated in both horizontal and vertical directions. This system can be equipped with multiple lenses and digital processing controllers. One machine with multiple uses, saving costs.

1. Ultra-long detection range, covering large-scale pipelines

Equipped with GFRP rigid carbon fiber detection lines, it supports an ultra-long detection range of 10m to 120m. It perfectly suits the long-distance pipeline detection requirements of large factories, urban pipelines, power projects, etc., without the need to move the equipment in segments, significantly improving operational efficiency.

2. Multiple specifications of probes for adaptation, covering all pipe diameters

Available in 8mm/17mm/28mm/32mm/42mm/50mm and other diameters, it can precisely cover small-diameter branch pipes to large-diameter main pipes.

Supports axial 360° and radial 180° rotation scanning, combined with a 100°-150° wide-angle field of view, scanning the inner wall of the pipeline without blind spots, easily handling different pipe diameters' detection tasks.

3. Multiple levels of high-definition quality, precise defect recognition

Available in 700 lines/900 lines/1200 lines high resolution, combined with high-brightness LED white light source, it can present clear and color-representative real-time images in complex dark pipeline environments.

Supports fixed-focus/zoom functions, allowing for flexible switching between panoramic scanning and microscopic detail observation, accurately capturing minor defects and hidden dangers such as corrosion, cracks, blockages, and foreign objects.

4. Intelligent control and high-definition display, upgraded operation experience

Equipped with 7"/8"/10" high-definition TFT monitors, 16:9 wide-screen display, supporting photo, video, playback, image zooming and other multi-functional operations, making it clear and intuitive to view on-site detection and data recording.

Built-in 512Hz positioning transmitter (optional), enabling precise positioning of pipeline positions, combined with software for data management, facilitating later analysis and report generation.

5. Robust and durable design, adaptable to harsh environments

The probe uses IP68-level waterproof and dustproof materials, capable of stable operation in underwater, high-humidity, and oil-contaminated environments, suitable for complex conditions such as municipal and chemical industries.

The working temperature range covers -20℃~60℃, capable of stable operation in both cold outdoor conditions and hot workshops, ensuring the reliability of detection results.

6. Portable storage and multi-functional configuration, cost reduction and efficiency improvement

Equipped with a portable reel, neatly stored and easy to transport, suitable for outdoor operations.

Optional accessories such as small star frame brackets, measuring meters, lens materials, etc., meet users' personalized needs, one machine for multiple uses, saving procurement and maintenance costs.

1. Municipal Water Supply and Drainage / Pipeline Inspection

This is applicable for daily inspections and fault troubleshooting of urban municipal water supply pipelines, rainwater and sewage pipelines, and gas pipelines. It can reach a length of 10-120 meters for the pipelines, clearly identify potential hazards such as corrosion, cracks, blockages, and accumulation of foreign objects on the inner walls of the pipes, precisely locate the problem locations, provide intuitive basis for pipeline maintenance and emergency repairs, and avoid blind excavation.

2. Industrial Pressure Pipelines / Chemical Pipeline Inspection

This is applied to industrial pressure pipelines and process pipelines in industries such as boilers, power plants, petrochemicals, and shipbuilding. It can efficiently detect pipeline weld defects, corrosion, scaling, and foreign object blockages, without the need to dismantle the pipelines, achieving non-destructive testing, ensuring industrial production safety, and reducing operation and maintenance costs.

3. Building Ventilation / Air Conditioning Pipeline Inspection

This is applicable for the cleaning acceptance and daily inspections of building air conditioning pipelines, ventilation pipelines, and smoke exhaust pipelines. It can quickly check the internal accumulation of dust, oil stains, mold, and foreign object blockages, verify the cleaning effect, and detect pipeline structural hazards, improving the operational efficiency and hygiene safety of the building ventilation system.

4. Electricity / Cable Pipeline Inspection

This is used for the inspection of cable pipelines, conduit pipes, and underground pipelines in the power and power construction industries. It can detect whether the pipelines are deformed, blocked, or waterlogged, confirm the cable laying status, detect pipeline hazards, ensure power transmission safety, and provide precise visual data support for cable maintenance and emergency repairs.

5. Special Customized Scenarios Inspection

It supports customizing various special requirements, such as deep wells, non-digging pipelines, and complex non-standard pipelines. It can customize probes, cable lengths, and supporting functions according to customer needs, adapt to special working conditions in mines, water conservancy, and municipal non-digging repairs, and meet the visual inspection needs of various complex pipelines.

Setup: Secure the right probe (8-50mm) to the GRP pole. Power on the 7"-10" HD screen, adjust the LED light.

Deploy: Feed the probe into the pipe. Control direction & rotation for 360° scanning. Use the 512Hz locator if needed.

Record: Take 1080P photos/videos. Zoom in for defects.

Finish: Retract the pole. Save/export data, clean the probe and reel for next use.
